The skid steer loaders, multi-functional engineering vehicles, multi-purpose engineering machine. Achieved a special chassis vehicle steering wheel equipment, wheel running gear, all-wheel drive, skid steer, random job site can be quickly replaced or mount devices using a variety of work on both sides of the wheel speed difference, to adapt to different working environment and job content.
· Ergonomically designed, operating safety
· Quick hitch system
· Balance weight platform optional
· Higher lifting height than similar products
· Stand on or walk behind
· Double hand grip
Feature:
1. Folding pedal designed, driver can stand up the pedal or walk behind to operate machine.
2. Clear instrument panel sign, operating conveniently.
3. Joystick handle optional, operating more comfortable.
4. International warranty engine, enjoy local 3 years free engine maintenance.
5. It is a easier maintenance machinery,upper cover and back guard plate can be easily opened and dismounted ,you also can easily discharge the wasted egine oil outside the body, replace the spare parts easily ,like filte,engine oil, oi filter, spark plug and so on.
Main performance parameter of HY360L Mini Skid Steer Loader :
Engine Brand | Briggs & Stratton |
Intended power | 13.5KW |
Nominal speed | 3000rpm |
Number of cylinders | 1 |
Intake method | natural |
Displacement | 420CC |
Emission standard | Euro5-EPA |
Rated load | 200kg |
Maximum load | 300kg |
Maximum lifting force | 350KN |
Travelling speed | 0-6km/h |
Working three and | 9s |
Working system pressure | 17-21bar |
Fuel tank volume | 5L |
Maximum operating height | 2490mm |
Height to bucket pin | 1670mm |
Overall vehicle height | 1390mm |
Maximum bucket height | 2180mm |
Overall length without attachments | 1540mm |
Overall length with standard bucket | 2160mm |
Maximum height unloading angle | 139mm |
Unloading height | 1564mm |
Unloading distance | 446mm |
Bucket turning angle at ground level | 25° |
Turning angle of the bucket at maximum | 115° |
Bucket volume | 0.06m3 |
Operating mass | 900kg |
Track type | 150*36*72mm |
