HT-5030 Mini Crawler Dumper Instruction
The crawler transporter is a dump truck made of rubber crawler chassis or steel crawler chassis. manufacturer quality assurance, long service life, high efficiency.
It is especially suitable for short-distance transportation of various complex terrains such as mountains, paddy fields, deserts, and hills.
Main features:
1. wide range of use, simple structure, smooth transmission, labor-saving operation, easy to realize automatic control.
2. Single-cylinder power system, low fuel consumption. Large traction, good climbing grip performance, and strong transportation capacity.
3. The turning radius is small and the maneuverability is flexible, especially suitable for narrow sites, reducing the cost of road construction.
4. Equipped with electric start, centralized handle, hydraulic take-off and landing, self-unloading, reduce labor intensity and improve transportation efficiency.
Excavator part:
Micro excavator Strong power, stable performance, easy operation, complete attributes, multi-purpose.
Full hydraulic system, a small machine, with a variety of configurations, work more easily.
Applications: land clearing, digging ditches and trenches, tundra breaking, drilling and crushing, forestry and wood grasping, and other scenarios.
Complex working conditions, good climbing grip performance, transporting goods bearing strong
Seat-driven crawler truck, suitable for all terrains
It can be applied to many kinds of complex terrain and undertake various transportation work.
Chassis: the use of thickened cast steel wear-resistant parts, crawler selection of engineering, hydraulic systems and gearboxes are Jiangsu big brand and imported parts.
Electric control system is in line with national safety standards JB design.
Wear-resistant: thickened agro-industrial rubber tracks, built-in steel wire winding, strong grip
Structural optimization engineering technology, can effectively extend the service life of the tracks, improve mechanical control, reduce fuel consumption.
The selected rubber formula meets the international standard, which can effectively enhance the physical properties of the tracks and slow down the aging of the rubber body.
HT-5030 Mini Crawler Dumper Parameter
| Mini Dumper Model | HT-5030 |
| Engine | Loncin 196CC |
| Cooling mode | Air-cooled |
| Fuel | Gasoline |
| Emission | Euro5 |
| Transmission | Forward:6/Rear:2 |
| Speed type | High-Low |
| Loading capacity | 300kg |
| Box length | 1045mm |
| Box width | 630mm |
| Box depth | 320mm |
| Box type | Split type |
| Track width | 180mm |
| Flow of pump | \ |
| Mini Dumper weight | 281kg |
| Overall dimension(L*W*H) | 1980*820*1060 |
| Start mode | Manual |
| Driving type | Mechanical |
| Steering mode | Manual |
| Unload mode | Manual |
| Loading quantity | 12sets/20GP |
| 24sets/40HQ |
|
|
